FOSET CO., LTD was founded in 1988, We are in production of Graphite electrodes (30000MT per Year), Carbon Additive(30000MT per Year), Calcium Aluminate(40000MT per Year)

Item		Unit	Norminal Diameter
			UHP		HP		RP
			≤Φ400	≥Φ450	≤Φ400	≥Φ450	≤Φ300	≥Φ350
Resistance	E	μΩ·m	≤5.5		≤6.5		≤8.5
	N		≤4.5		≤5.5		≤6.5
Bending Strength	E	MPa	≥11.0		≥10.5	≥9.8	≥8.5	≥7.0
	N		≥20.0		≥16.0		≥15.0
Elastic Modulus	E	GPa	≤14.0		≤12.0		≤9.3
	N		≤18.0		≤16.0		≤14.0
Bulk Density	E	g/cm3	≥1.66	≥1.67	≥1.62	1.60	≥1.53	≥1.52
	N		≥1.75		≥1.73		≥1.69
CTE.	E	10-6/℃	≤1.5		≤2.4		≤2.9
	N		≤1.4		≤2.2		≤2.8
Ash		%	≤0.3		≤0.3		≤0.5

Graphite electrode to allow the current load and current density (recommended)

Norminal Diameter	RP		HP		UHP
mm	Current load A	Current Density A/cm2	Current load A	Current Density A/cm2	Current load A	Current Density A/cm2
200	5000-6900	15-21	5500-9000	18-25
250	7000-10000	14-20	8000-13000	18-25	9200-15100	21-30
300	10000-13000	14-18	13000-17400	17-24	13000-22000	20-30
350	13500-18000	14-18	17400-24000	17-24	20000-30000	20-30
400	18000-23500	14-18	21000-32000	16-24	25000-40000	19-30
450	22000-27000	13-17	25000-40000	15-24	32000-45000	19-27
500	25000-32000	13-16	30000-48000	15-24	38000-55000	18-27
550	32000-40000	13-16	37000-57000	15-23	48000-60000	18-24
600	38000-47000	13-16	44000-67000	15-23	52000-72000	18-24
700	45000-54000	13-16	54000-73000	15-23	62000-95000	18-24

Cone size of graphite electrode joints
Unit: mm

Diameter			Nipple				Socket		Pitch
			D	d2	L	l	d1	H
			Tolerance：			≤	Tolerance：
	mm	in	（-0.30～0）	（-0.30～0）	（-1～0）	≤	（0～0.3）	（0～7）	8.47
3TPI	225	9″	139.70	91.22	203.20	7	141.22	107.60
	250	10″	155.57	104.20	220.00		157.09	116.00
	300	12″	177.16	117.39	270.90		148.68	141.50
	350	14″	215.90	150.48	304.80		217.42	158.40
	400	16″	215.90	150.48	304.80		217.42	158.40
	400	16″	241.30	170.23	338.70		242.82	175.30
	450	18″	241.30	170.23	338.70		242.82	175.30
	450	18″	273.05	199.17	355.60		274.57	183.80
	500	20″	273.05	199.17	355.60		274.57	183.80
	500	20″	298.45	221.73	372.60		299.97	192.20
	550	22″	298.45	221.73	372.60		299.97	192.20
	600	24″	336.55	245.73	457.30		338.07	234.60
3TPIL	350	14″	215.90	144.85	338.70		217.42	175.30
	400	16″	241.30	167.43	355.60		242.82	183.80
	450	18″	273.05	182.23	457.30		274.57	234.60
4TPI	200	8″	122.24	81.48	177.80	7	115.92	94.90	6.35
	225	9″	139.70	98.94	177.80		133.38	94.90
	250	10″	152.40	109.52	190.50		146.08	101.30
	300	12″	177.80	130.69	215.90		171.48	114.00
	350	14″	203.20	149.74	254.00		196.88	133.00
	400	16″	222.25	160.32	304.80		215.93	158.40
	450	18″	241.30	179.37	304.80		234.98	158.40
	500	20″	269.88	199.49	355.60		263.56	183.80
	550	22″	298.45	228.06	355.60		292.13	183.80
	600	24″	317.50	247.11	355.60		311.18	183.80
	650	26″	355.60	268.27	457.20		349.28	234.60
	700	28″	374.65	287.32	457.20		368.33	234.60
4TPIL	300	12″	177.80	124.34	254.00		171.48	133.00
	350	14″	203.20	141.27	304.80		196.88	158.40
	400	16″	222.25	151.86	355.60		215.93	183.80
	450	18″	241.30	170.91	355.60		234.98	183.80
	500	20″	269.88	182.55	457.20		263.56	234.60
	550	22″	298.45	211.12	457.20		292.13	234.60
	600	24″	317.50	230.17	457.20		311.18	234.60
	650	26″	355.64	251.38	558.80		349.28	285.40
	700	28″	374.65	270.39	558.80		368.33	285.40

The Plant of Graphite electrode has a complete producing line from material-calcining (three set ) to Extrusion (one set 3500 tons pressure, two sets 2500 tons pressure)、Impregnation (two set of vacuum impregnation)、Graphitization (two set LWG Graphitization Furnace) 、the machining process ( computer control). We are supplying Ø100-Ø700mm Graphite Electrode with specification RP, HP, SHP and UHP. Our products have been exported far to America, Japan, Europe, Africa and Southeast Asia.

The Plant of Carbon Additive has 5 set calcining furnace, and we can supply 30000MT/year with 9 of type of Carbon additive (C content from 90% to 99%). Especially our product has advantage of low sulfur、hydrogen oxygen、nitrogen content. Our products have been exported far to Europe, North and South America and Southeast Asia.

The Plant of Pre-melted Calcium Aluminate has 3 of the Gas Melting furnace, they can produce Calcium Aluminate 40000 tons per year. Especially our product has the advantage of content, low Ferro content and low melting point. Our products mainly export to Europe and Middle East.

We have already greatly penetrated in the world market, and are supplying many advantageous materials to the foreign market. We have set up friendly and stable business relation with hundreds of clients from allover the world. We are enjoying reputation with our high quality and competitive price. Honesty and promise-keeping are our religion.
